Aten VE1843 True 4K HDMI / USB HDBaseT 3.0 Transceiver
Product Description
The VE1843 is ATEN ’s fi rst video transceiver and integrates the functions of a transmitter and a receiver into one unit. This combination allows users to easily confi gure the unit to be a transmitter or receiver depending on their AV solution, and to enjoy more fl exible deployment and effective use with video matrix switches, video splitters, etc.
Key Features
- Extends uncompressed True 4K HDMI signals up to 100 m over a single Cat 6a cable (HDBaseT 3.0 Certified Cat 6a U/ FTP cable* / ATEN 2L-29330 Cat 6a cable) with zero latency
- Flexible for deployment – can be configured as a transmitter or receiver depending on the AV solution
- Compliant with HDBaseT 3.0 standards – transmits high-quality video, full range IR, bi-directional RS-232, Gigabit Ethernet, independent stereo audio and USB 2.0 signals channel bypass
- HDMI (3D, Deep Color, 4K/60Hz); HDCP 2.3 compliant
- Superior video quality – up to 4096 x 2160 @ 60 Hz (4:4:4); HDR, HDR 10+, Dolby Vision supported
- Supports HDMI audio embedding / de-embedding functions
- Supports HDMI audio embedding / de-embedding functions
- Compliant with the USB 2.0 standard for a wide range of USB peripherals compatibility
- LED indication of HDBaseT and HDMI signal status for easier recognition
- Fanless fin heat sink enclosure – elevates durability and reliability by preventing overheating, fan malfunctions, and noises
- Supports extremely high refresh rates up to 240 Hz for the connected display
- Firmware upgradable
- Built-in 8KV / 15KV ESD protection
- Plug-and-play
- Rack-mountable
Product Code
Product Name
Add to Basket
Aten VE1843 True 4K HDMI / USB HDBaseT 3.0 Transceiver
VE1843
True 4K HDMI / USB HDBaseT 3.0 Transceiver
