Aten VM5404D / VM5808D Video Wall Controller

Product Description

The Aten VM5404D / VM5808D seamless Video matrix switch for DVI signals that offers an easy and affordable way to route any of 4/8 DVI video sources to any of 4/8  DVI displays.

The VM5404D / VM5808D includes seamless switching that employs an FPGA matrix architecture to ensure continuous video streaming, real-time control and stable signal transmission. With a built-in high-performance scaler, the VM5404D easily converts various input resolutions into a array of output resolutions, giving viewers the best image quality across all displays. The switch also integrates video wall functionality with an easy-to-use web GUI that lets you create 8 connection profiles for convenient layout customization.

The VM5404D / VM5808 is the ideal solution for any control center streaming multiple sources to multiple displays.

Key Features

  • Configuration and Control via pushbuttons / IR Remote Control
  • System Operation via bi-directional RS-232 serial controller / Browser Graphical User Interface (GUI) / Telnet
  • Built-in Scaler on each output port converts input resolutions into the display’s native resolution, supports scaling 1920 x 1200 resolutions up or down
  • Video Wall – features up to 8 video wall profiles for custom screen layouts via point-n-click web GUI
  • EDID Expert – configures optimum EDID settings for smooth power-up, high-quality display and use of the best resolution across different screen
  • Firmware Upgradeable
  • Rackmount

Product Code

Product Name

Add to Basket

Aten VM5404D / VM5808D DVI 4X4 or 8X8 Video Matrix Switch with scaler & inbuilt Video Wall controller
DVI 2X2 Video Wall Controller with 4X4 Video Matrix Switch

DVI 4X4 Video Wall Controller with 8X8 Video Matrix Switch
