SY Electronics MFT62 Video Matrix Switcher

Get a Quote
Manufacturer
Produced In
China
Download SY Electronics MFT62 Datasheet

Product Description

The MFT62  is a compact 4K UHD, 6 Input, 2 Output Multi-Format Switcher, with independently matrixed HDMI and HDBaseT outputs. This unit is also available as the ‘MFT62-SET’ which is also supplied with our ‘Slim70 Pro’ HDBaseT receiver.

This device is well suited for use in auditoriums, public venues, and conference/meeting rooms.

Key Features

  • Inputs and Outputs - The 6 inputs consist of 4x HDMI, 1x VGA + Audio, 1x Display Port input. Outputs consist of 1x HDMI and 1x HDBaseT output.
  • Audio output – Audio can be de-embedded via an analogue output using the 3x pin phoenix terminal connectors. By default the audio is matched to the HDBaseT output, but can be changed to match the HDMI output by sending an RS232 command to the unit.
  • Matrix Switching - Any source can be routed to either or both of the outputs as required
  • Control – A choice of front panel buttons, IR, RS232 or external contact closures enable control over the unit. Control over the HDBaseT link is bi-directional, with the ability to control the display from the source location and the source from the display location.
  • Auto Switching – Manual or Automatic source selection is controlled by front panel buttons or RS232 commands.
  • Contact Button Terminals – Rear mounted contact closure terminals are provided for connection of remote contact button panels.
  • Source Status – The status of selected inputs can be read from the front panel mounted LED indicators
  • EDID – Extensive control is afforded by selecting one of the 24x built-in EDIDs, or you can choose to read an EDID from a connected display and stored onto one of the 3x user programmable EDID memory positions.
  • Inputs - 4x HDMI, 1x DisplayPort, 1x VGA inputs
  • Outputs - Independent HDMI and HDBaseT Matrix outputs
  • HDBaseT PoC powers remote Slim 70 Receiver
  • HDBaseT output to 70m @1080p or 40m @4K30
  • Auto input switching and monitor on/off options
  • Control: Front Panel, Bi-directional IR, RS232, contact closure
  • Independent RS232-CTL for device control
  • L/R de-embedded audio
  • Extensive EDID Management

Product Code

Product Name

Add to Basket

SY Electronics MFT62 Video Matrix Switcher
MFT62
A 4K UHD, 6 Input / 2 Output Multi-Format Switcher, with HDMI and HDBaseT outputs.
