Adder Infinity Manager KVM Matrix over IP

Manufacturer
Produced In
United Kingdom

Product Description

The Adder A.I.M. management server is a control suite which transforms AdderLink Infinity extenders into a digital matrix switch solution. Using standard IP infrastructure it is possible to route any user station to any computer attached to the network without any compromises to video quality or control. It allows co–operative sharing of computers and the multicasting of video to any destination

Secure access and communications Using TLS (transport layer security) and HTTPS, communications between AdderLink units and A.I.M. and between A.I.M. and the outside world are all secure.

Redundant operation For 24/7 reliability a second hot A.I.M. can be added to ensure constant uptime and with dual NIC interfaces on every AdderLink Infinity unit, systems can be easily designed for maximum resilience.

User access rights management and audit trails Administrators can manage access rights to each device on a user by user basis either manually through the web browser or automatically using Active Directory. Reports showing the history of devices, user logins and device connections can be viewed and exported to a CSV file or via SYSLOG.

Easy centralized management Accessed via a web browser, the dashboard gives a real time overview of system connections and users. Tabs enable you to navigate between settings and device or user sub-menus

Control Channel and Presets connections A.I.M. can be used to make connections between an individual pair of transmitter and receiver devices centrally from within the management system. Using Presets, a list of pre-defined connections, multiscreen, video wall or signage setups can be forced with a single click.



Key Features

  • On screen display at each user station Users login and choose channel connections from an intuitive OSD similar to that of a Digital TV. Users can also use Presets to change channels for multiple screens across multiple receivers.
  • Remote OSD The remote OSD allows the user to “push” video and control to another station or to a video wall or projector.
  • Favourites and hotkey switching Each user can select their favourite channels within the OSD and allocate a hotkey for fast switching between channels.
  • Choice of connection modes Administrators can choose to give users the ability to connect in three modes: View only, Shared or Exclusive. Each permitted mode is then made available within the
  • Fast video and USB switching The switching time between computers is less than 1 second to provide a quality user experience.
  • Multicasting Network multicasting allows the system to share video simultaneously from one transmitter to an unlimited number of receivers. Suitable for signage, monitoring and sharing of desktops.
  • USB sharing USB sharing allows multiple users to connect to and control a single computer at the same time. Each transmitter can report 12 unique USB devices (identified by VID/PID codes) but will merge devices with the same ID to allow many more.
  • Channels Considered as a Virtual Transmitter, a channel may combine video, audio and USB from different transmitters as a single source. Ideal where audio alerts or mixed video sources are required.
  • Open API for 3rd party control systems Adder Technology publishes a simple API structure to allow easy integration with other 3rd Party control systems supplied by companies like AMX, Crestron , HRS or MediaLon at a HTTP level.
  • SNMP v3 get / walk External machines can interrogate A.I.M. to find out the status of the AdderLink Infinity network and units. SNMP v3 security is implemented, supporting AES/DES transport with MD5/SHA authentication.
  • External NTP server support – NTPv4.2 Connect up to 3 NTP servers with authenticated connections using MD5 and Key ID as defined in the NTP standards. All AdderLink Infinity units in an A.I.M. network now get time using authenticated NTP from A.I.M.

Product Code

Product Name

Add to Basket

Adder Infinity Manager KVM over IP Switch - Server
AIM-24
AdderLink Infinity Manager Device including 24 end point license - supports 24 End Points

AIM-48
AdderLink Infinity Manager Device including 48 end point license- supports 48 End Points

AIM-96
AdderLink Infinity Manager Device including 96 end point license - supports 96 End Points

AIM-192
AdderLink Infinity Manager Device including 192 end point license supports - 192 End Points

AIM-288
AdderLink Infinity Manager Device including 288 end point license - supports 288 End Points

Adder Infinity Manager KVM over IP Switch - License
AIMLIC-48
AdderLink Infinity AIM Software upgrade Licence up to 48 end points

AIMLIC-48-BCK
AdderLink Infinity AIM Software upgrade Licences for Primary and Failover units up to 48 End Points

AIMLIC-96
AdderLink Infinity AIM Software upgrade Licence up to 96 end points

AIMLIC-96-BCK
AdderLink Infinity AIM Software upgrade Licences for Primary and Failover units up to 96 End Points

AIMLIC-192
AdderLink Infinity AIM Software upgrade Licence up to 192 end points

AIMLIC-192-BCK
AdderLink Infinity AIM Software upgrade Licences for Primary and Failover units up to 192 End Points

AIMLIC-288
AdderLink Infinity AIM Software upgrade Licence up to 288 end points

AIMLIC-288-BCK
AdderLink Infinity AIM Software upgrade Licences for Primary and Failover units up to 288 End Points

AIMLIC-UNL
AdderLink Infinity AIM Software upgrade Licence with unlimited end points

AIMLIC-UNL-BCK
AdderLink Infinity AIM Software upgrade Licences for Primary and Failover units with Unlimited End Points
